PLR compressed air laboratory stirrers up to 30 l for use in potentially explosive atmospheres, with tachometer
0,00 €
Info sui prodotti "PLR compressed air laboratory stirrers up to 30 l for use in potentially explosive atmospheres, with tachometer"
General specifications:
- operating pressure max. 6 bar
- air consumption 260 l/min. at 6 bar
- power output 200 W at 6 bar
- clockwise rotation
- ATEX certification
Basic models include:
- all-stainless steel housing
- continuously adjustable speed control valve
- support arm diam. 14 mm
- snap connection for NW 5
- output shaft L x diam. 26 x 10 mm
The viscosity data are intended as a guideline.
| ATEX certification: | Ex II 2G Ex h IIC T5 Gb |
|---|---|
| Compressed air consumption: | 260 l/min |
| Display: | Analogue |
| Idle speed: | 950 1/min |
| Manufacturer Article Number: | 40 26446 00261 9 |
| Max. Viscosity: | 70000 mPa·s |
| Max. operating pressure: | 6 bar |
| Max. stirring capacity: | 30 l |
| Nominal torque: | 5.3 Ncm |
| Operating press bar: | 6 bar |
| Rated capacity: | 200 W |
| Type: | PLR 12T |
| UNSPSC: | 41103810 |
Login
Other customers also bought
PLR compressed air laboratory stirrers are designed for all kinds of standard mixing tasks. The vane type, air-driven motor offers a high power density and is significantly lighter and smaller than an equivalent electric motor.General specifications:operating pressure max. 6 barair consumption 260 l/min. at 6 barpower output 200 W at 6 barclockwise rotationATEX certificationBasic models include:all-stainless steel housingcontinuously adjustable speed control valvesupport arm diam. 14 mmsnap connection for NW 5output shaft L x diam. 26 x 10 mmThe viscosity data are intended as a guideline.
